Rotary Vane type Vacuum Pump (1 to 20 HP)

Send Inquiry

Request To Call Back

Rotary Vane type Vacuum Pump (1 to 20 HP)

Get a Price/Quote

MOQ : 1 Unit

Rotary Vane type Vacuum Pump (1 to 20 HP) Specification

Noise Level
65 - 75 dB(A)

Mounting Type
Base Mounted (Horizontal)

Fuel Tank Capacity
N/A - electric powered

Frequency
50 Hz / 60 Hz

Caliber
As per design - generally DN25 to DN65

Voltage
415 V / 50 Hz

Features
Low maintenance, High efficiency, Compact design, Air cooled

Flow Rate
40 to 1200 m3/h (varies by model)

Max Suction
0.1 mbar max vacuum

Control System
Manual/Automatic (optional)

Speed
1450-1720 rpm

Head Size
Variable - based on model

Working Temperature
5C to 80C

Inlet/Outlet
Threaded or Flanged

Discharge Pressure
Atmospheric

Theory
Rotary Vane Principle

Material
Cast Iron / Aluminum Alloy / Stainless Steel

Structure
Single/Double Stage Rotary Vane

Power
1 to 20 HP

Product Type
Rotary Vane type Vacuum Pump

Standard
CE/ISO Certified

Fuel Type
Electric

Pressure
Low pressure / High vacuum

Color
Grey

Usage
Industrial Vacuum, Laboratory, Packaging, Pharmaceutical, Chemical Processing

Application
Industrial, Medical, Research, Food processing

Suction Type
Dry Oil Lubricated)

Seals Type
Oil-Sealed

Priming
Self-priming

Pump Type
Rotary Vane Vacuum Pump

Capacity
40-1200 m3/h

Moisture Separator
Optional

Vacuum Gauge
Integrated (standard)

Ultimate Pressure
up to 0.1 mbar absolute

Oil Mist Filter
Supplied as standard

Oil Capacity
2 to 12 liters (based on model)

Cooling Method
Air cooled

Dimensions
Varies by model

Lubrication System
Forced oil lubrication

Protection Class
IP54 / IP55 motor

Weight
60 to 450 kg (depending on model)

Rotary Vane type Vacuum Pump (1 to 20 HP) Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
100 Units Per Day

Delivery Time
1 Week

Main Domestic Market
Gujarat

About Rotary Vane type Vacuum Pump (1 to 20 HP)

Rotary Vane type Vacuum Pump (1 to 20 HP)

4 Single Stage Vaccum Pump

4 Continuous operation from atm pressure to end Vaccum

4 Integrated Oil mist Filter on the exhaust

4 High Pumping speed even at low pressure

4 Low maintenance cost, silent & robust

Efficient and Robust Performance

Designed for reliability, the rotary vane type vacuum pump combines forced oil lubrication and an integrated vacuum gauge to maintain peak performance across diverse industries. The air cooling system ensures stable operation even during prolonged use, while single or double stage structures offer flexibility for specific application needs. With extensive compatibility and self-priming capabilities, this pump is ideal for research labs, food processing, and packaging facilities.

Low Maintenance, High Efficiency

With features such as oil-sealed design, oil mist filter, and optional moisture separator, this vacuum pump ensures clean operation and reduces the need for frequent maintenance. Its compact and base-mounted structure saves space, while the range of models (1-20 HP) allows customization for flow rates, pressure requirements, and installation needs. Certified for safety and industrial use, it is trusted by suppliers and traders across India.

FAQ's of Rotary Vane type Vacuum Pump (1 to 20 HP):

Q: How does the rotary vane vacuum pump achieve and maintain its high vacuum levels?

A: The pump operates on the rotary vane principle, using vanes mounted in a rotating rotor within a sealed chamber. Forced oil lubrication, air cooling, and integrated oil-sealed design support reliable and stable vacuum levels down to 0.1 mbar absolute.

Q: What are the main benefits of an air-cooled, oil-lubricated rotary vane vacuum pump?

A: Air cooling eliminates the need for complex water systems, enhancing reliability and simplifying installation. Forced oil lubrication prolongs component life, reduces friction, and maintains efficient vacuum creation with minimal maintenance requirements.

Q: Where can this vacuum pump be used?

A: This rotary vane vacuum pump is suitable for industrial, laboratory, packaging, pharmaceutical, chemical processing, food processing, and research applications, supporting everything from process vacuum to laboratory experiments.

Q: What maintenance is required for this vacuum pump?

A: Routine maintenance primarily involves checking and replacing oil, inspecting the oil mist filter and, if equipped, the moisture separator. Its design emphasizes low maintenance through durable materials and efficient lubrication.

Q: When is a moisture separator recommended as an optional feature?

A: A moisture separator is beneficial in processes with high humidity or moisture-laden gases entering the pump. It prevents water vapor from contaminating oil and internal components, prolonging pump lifespan.

Q: What is the process for integrating the pump into an industrial setup?

A: Mount the unit horizontally on a stable base, connect inlet/outlet ports (threaded or flanged), ensure electrical supply matches the voltage and frequency, and verify all safety features such as the oil mist filter are in place. The system supports both manual and optional automatic controls.
