Air Cooled Reciprocating Lubricated Vacuum Pump (2 to 10 HP)

Send Inquiry

Request To Call Back

Air Cooled Reciprocating Lubricated Vacuum Pump (2 to 10 HP)

Get a Price/Quote

MOQ : 1 Unit

Air Cooled Reciprocating Lubricated Vacuum Pump (2 to 10 HP) Specification

Discharge Pressure
Atmospheric

Mounting Type
Base Mounted

Head Size
Customizable

Flow Rate
50-500 LPM

Inlet/Outlet
Threaded / Flanged

Speed
850-1440 RPM

Control System
Manual / Automatic

Theory
Reciprocating

Max Suction
700 mm Hg (approx.)

Features
Air cooled, High durability, Easy operation, Low maintenance, Superior vacuum efficiency

Caliber
Standard

Working Temperature
Up to 60C

Noise Level
Below 75 dB

Frequency
50 Hz

Voltage
220-415 V, 50 Hz

Material
Cast Iron / Aluminium

Structure
Air Cooled Reciprocating

Power
2 to 10 HP

Standard
ISI / ISO Certified

Product Type
Air Cooled Reciprocating Lubricated Vacuum Pump

Fuel Type
Electric

Color
White

Pressure
Up to 10 bar

Usage
Vacuum Generation

Application
Laboratories, Chemical Industry, Food Processing, Pharmaceutical, Packaging

Suction Type
Dry

Seals Type
Oil Seals

Priming
Self-priming

Pump Type
Lubricated Vacuum Pump

Capacity
2 to 10 HP

Service Duty
Continuous

Number of Cylinders
Single/Double

Vacuum Gauge
Provided

Weight
45-120 kg depending on model

Construction
Sturdy design for continuous operation

Surface Finish
Powder Coated / Painted

Safety
Equipped with safety valve

Rotating Direction
Clockwise (view from pulley side)

Cooling
Air Cooled

Lubrication Type
Forced Splash Lubrication

Air Cooled Reciprocating Lubricated Vacuum Pump (2 to 10 HP) Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
100 Units Per Day

Delivery Time
1 Week

Main Domestic Market
Gujarat

About Air Cooled Reciprocating Lubricated Vacuum Pump (2 to 10 HP)

Air Cooled Reciprocating Lubricated Vacuum Pump (2 to 10 HP)

4 Cast iron design for durability and long life

4 Low noise - Ideal for hospital applications

4 Higher efficiency resulting in power savings

4 Compact & easy to install - No foundation required

4 Low oil carry over &maintenance cost

4 Tank and Base mounted versions available.

Efficient and Reliable Vacuum Generation

Our air cooled reciprocating lubricated vacuum pump stands out due to its superior vacuum efficiency and robust construction. Engineered with high-grade cast iron or aluminium and featuring a powder-coated or painted surface, this pump is built to last in continuous industrial operations. Its design supports air cooling for optimal thermal management and incorporates a forced splash lubrication system, ensuring reliable performance with minimal maintenance.

Versatile and User-Friendly Operation

The pump supports both single and double cylinder configurations, and models cover a power range from 2 to 10 HP. With suction capabilities up to 700 mm Hg and customizable head size, this unit adapts to a wide variety of industrial applications. Featuring a self-priming, dry suction system, and both manual and automatic control systems, it ensures flexible and easy operation in any environment.

Safe and Certified for Industrial Use

Safety comes first: an integrated safety valve and vacuum gauge are standard, and the pump adheres to international ISI and ISO certifications. With an operational noise level below 75 dB, it remains workplace-friendly. A sturdy design and powder-coated finish boost longevity, making it ideal for retailers, suppliers, traders, and wholesalers in India's industrial market.

FAQ's of Air Cooled Reciprocating Lubricated Vacuum Pump (2 to 10 HP):

Q: How does the Air Cooled Reciprocating Lubricated Vacuum Pump achieve reliable vacuum generation?

A: The pump utilizes a reciprocating mechanism powered by an electric motor (2-10 HP), drawing air through threaded or flanged inlets with self-priming action. Forced splash lubrication and air cooling ensure continuous, stable operation while oil seals maintain vacuum integrity. Its robust construction and precise engineering result in high and consistent vacuum, suitable for industrial applications.

Q: What industries can benefit from using this vacuum pump?

A: This pump is ideal for laboratories, the chemical industry, food processing, pharmaceutical manufacturing, and packaging sectors. Its sturdy design, customizable specifications, and compliance with ISI/ISO standards address the diverse needs of these demanding environments.

Q: When should I consider using a lubricated, air cooled vacuum pump over other types?

A: Choose this pump when you require continuous-duty vacuum generation, high durability, and minimal maintenance in environments where water cooling is impractical. The air cooled system and forced splash lubrication allow for sustained operation up to 60C without complex infrastructure or frequent servicing.

Q: Where can this pump be installed, and how is it mounted?

A: The pump is base mounted and can be installed indoors in industrial sites, labs, or manufacturing units. Its compact, vibration-resistant structure facilitates installation on solid floors, and the noise level below 75 dB makes it suitable for workplaces where quiet operation is valued.

Q: What is the process of vacuum generation in this reciprocating pump?

A: The electric motor rotates the crankshaft, causing pistons to move within single or double cylinders. This reciprocation draws air in through the inlet, creating a vacuum through the suction stroke, and then expels air through the outlet during the compression stroke, all while lubrication is maintained by a forced splash system.

Q: How does the pump ensure safety during operation?

A: Safety features include a factory-fitted safety valve to release excess pressure and a vacuum gauge to monitor performance. Its powder-coated/painted exterior guards against corrosion, while the oil seal design and sturdy build prevent leaks and operational hazards.

Q: What maintenance benefits does this vacuum pump offer?

A: Thanks to the air cooled, forced splash lubrication system and durable construction, maintenance requirements are minimal. Routine checks on oil level, seals, and the safety valve should keep the unit running efficiently, while ISI/ISO certifications ensure reliable and standardized service life.
